Quad Darlington Switch Four Non Inverting Inputs With Enable Output Voltage Up To 60 V L6221c

Product Categories

Anterwell Technology Ltd.

Contact Now

Quad Darlington Switch Four Non Inverting Inputs With Enable Output Voltage Up To 60 V L6221c

Name: Quad Darlington Switch Four Non Inverting Inputs With Enable Output Voltage Up To 60 V L6221c
Brand: VISHAY
Price: 1 USD

Brand Name : VISHAY

Model Number : L6221C

Certification : Original Factory Pack

Place of Origin : Original

MOQ : 5pcs

Price : Negotiation

Payment Terms : T/T, Western Union,PayPal

Supply Ability : 290PCS

Delivery Time : 1 Day

Packaging Details : please contact me for details

Output Voltage : 60 V

Logic Supply Voltage : 7 V

Input Voltage, Enable Voltage : VS

Continuous Colllector Current (for each channel) for L6221CD : 1.8 A

TJ (maximum) : 150 °C

Contact Now

Quad Darlington Switch Four Non Inverting Inputs With Enable Output Voltage Up To 60 V L6221c ♦ FOUR NON INVERTING INPUTS WITH ENABLE

♦ OUTPUT VOLTAGE UP TO 60 V

♦ OUTPUT CURRENT UP TO 1.8 A

♦ VERY LOW SATURATION VOLTAGE

♦ TTL COMPATIBLE INPUTS

♦ .INTEGRAL FAST RECIRCULATION DIODES

DESCRIPTION

The L6221 monolithic quad darlington switch is designedforhigh current,high voltageswitchingapplications. Each of the four switches is controlled by a logic input and all four are controlled by a common enableinput.AllinputsareTTL-compatiblefordirect connectionto logic circuits. Eachswitch consistsofan open-collectordarlington transistorplus a fastdiodeforswitchingapplications withinductivedevice loads. The emittersof thefourswitches are commoned.Any numberof inputsand outputsof the same device may be paralleled. Three versions are available : the L6221Cmounted in a Powerdip12+ 2 + 2 packageand the L6221CN mounted in a 15--lead Multiwatt package, the L6221CDin SO16+2+2package.
